Product Details:
|
| Material: | High Chromium,GCr15SiMn,100CrSiMn6-4 | Degree Of Accuracy: | G60 |
|---|---|---|---|
| Hardness: | HRc60 To HRc67 | Application: | Power Plant, Slewing Ring Bearing |
| Surface: | Bright, Grinding, High Polished | Properties: | Excellent Wear Resistant |
| Package: | Plastic Bag + Cardboard Box + Wooden Pallet | Dimensions: | 62.95mm,62.96mm,62.97mm,62.98mm,62.99mm |
| High Light: | G60 Grinding Steel Ball,62.94mm Grinding Steel Ball,63.06mm Grinding Steel Ball |
||
62.96mm(2.478740"), 62.94mm to 63.06mm, grinding steel balls for bearing, G40 Or G60
Introduction
Chromium (Gcr15SiMn, 100CrSiMn6-4,SUJ3) steel balls, also called bearing steel balls. The high-precision chromium steel ball contains chromium and has excellent surface quality and high bearing capacity due to being quenched.
Throughout the manufacturing process, statistical process control can ensure tolerance accuracy, good surface finish and consistent high quality. It is most widely used in the ball and roller bearing industry and various wind power applications.
The chromium ball is made of the highest quality chromium alloy steel and is quenched to achieve maximum strength and service life. Ideal applications for chrome balls include rolling media, spray tank mixing, ball bearings, wind turbine bearings, and linear motion components. The most widely used in various industries.
A
We mainly produce chromium steel with a size of 7.9375mm to 82.55mm. The main material is high chromium GCR15 or GCR15SiMn.Most importantly, we can customize our products to suit various needs of our customers.
The ball has high precision, good surface smoothness, standard hardness and excellent wear resistance. Our products have been widely exported to Europe, America, Japan, Korea etc.
GCr15 notice:
1. The residual copper content (melting analysis) of the steel for bearing steel pipes should not exceed 0.2%.
2. The oxygen content is measured on the billet or steel.
3. The sulfur content (melting analysis) of wire rod steel should not exceed 0.02%.
Parameter
| Ball Diameter | Grade | Hardness | Material |
| 62.96mm(2.478740") | G40 or G60 | HRc 60-67 | GCr15SiMn,100CrSiMn6-4,SUJ3,52100 |
Grade and Tolerance
| Precision / Grade |
Ball Diameter Tolerance |
Deviation from Spherical Form |
Maximun surface roughness |
Lot diameter variation |
| G40 | 1 | 1 | 0.06 | 2 |
| G60 | 1.5 | 1.5 | 0.08 | 3 |
Chemical composition(mass fraction)(wt.%) of the GCr15SiMn
| Carbon | 0.95 to 1.05% |
| Chromium | 1.40 to 1.65% |
| Manganese | 0.95 to 1.25% |
| Silicon | 0.45 to 0.75% |
| Copper | 0.25% maximum |
| Nickel | 0.30% maximum |
| Sulfur | 0.025% maximum |
| Phosphorous | 0.025% maximum |
Product Details
| Product Name | High Chrome Grinding Steel Balls |
| Size range | Ø 62.94 mm – Ø 63.06 mm(GCr15SiMn/SUJ3/100CrMn6 high Chrome Steel Balls) |
| Quality grades | G40 or G60 for balls Ø62.94mm to 63.06mm |
| Hardness |
For 63mm group ball, a minumun core hardness at centre of the ball shall be HRc55. a minumun hardness at surface of the ball shall be HRc60. a minumun hardness at depth of 15% ball diameter shall be HRc58. |
| Application | The High Quality Chrome Steel Balls are mainly applied in Deep Groove Ball Bearing, Angular Contact Ball Bearings, Thrust Ball Bearings, Wheel Hub Bearings, Linear Bearings,wind turbine bearing, slewing ring bearing and also the Bearing. |
Properties and Advantage
[High-quality material] Made of high-quality chromium steel, high-grade bearing steel, corrosion resistance, high precision and high hardness. Polished surface, smooth without burrs, standard shape and high precision, completely round.
[Anti-rust] Corrosion resistance and high oxidation resistance. It is also suitable for humid environments. The surface is coated with a small amount of grease to improve lubrication and prevent corrosion and rust.
[Long use] The heat treatment process can make the bearing ball stronger and bear high pressure and wear resistance.
[Wide application] Widely used in wind turbine bearings, yaw bearing, slewingring bearing and so on.
